Specifications

Frame & Fork

Frame

• OCLV Mountain Carbon
• Tapered head tube
• Internal derailleur and dropper post routing
• PressFit 121mm bottom bracket
• 197x12mm adjustable horizontal sliding dropouts

Fork

• Farley carbon
• Tapered alloy steerer
• Crown rack mounts
• Lower-leg cage mounts
• 150x15mm thru axle

Wheels & Tires

Front Hub

• Bontrager alloy, sealed bearing, 6-bolt, 15x150mm thru axle

Front Skewer

• Bontrager Switch thru axle

Rear Hub

• Bontrager alloy, sealed bearing, 6-bolt
• 108T Rapid Drive
• SRAM XD driver
• 197x12mm thru axle

Rear Skewer

• Bontrager Switch thru axle, removable lever

Rims

• SUNRinglé Mulefut 80 SL, 32-hole cutout

Tires

• Bontrager Barbegazi Team Issue
• Tubeless Ready
• Inner Strength sidewalls
• Aramid bead
• 120 tpi
• 27.5x4.50"

Maximum Tire Size

• Frame: 27.5x4.50" or 26x4.70"
• Fork: Refer to manufacturer

Drivetrain

Shifter

• SRAM GX Eagle, 12-speed

Rear Derailleur

• SRAM GX Eagle

Crankset

• Size S, M: SRAM GX Eagle, DUB, 30T alloy FAT 5 ring, 170mm
• Size L, XL: SRAM GX Eagle, DUB, 30T alloy FAT 5 ring, 175mm

Bottom Bracket

• SRAM DUB, 121mm, PressFit

Cassette

• SRAM Eagle XG-1275, 10-52, 12-speed

Chain

• SRAM GX Eagle, 12-speed

Pedals

• VP-536 nylon platform

Max Chainring Size

• 1x: 32T
• 2x: 36/22

Cockpit & Contact Points

Saddle

• Bontrager Verse Elite
• Austenite rails
• 145mm width

Seatpost

• Size S: TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm
• Size M: TranzX JD-YSP18, 120mm travel, internal routing, 31.6mm, 403mm
• Size L, XL: TranzX JD-YSP18, 130mm travel, internal routing, 31.6mm, 425mm

Handlebar

• Bontrager Rhythm Comp, alloy
• 31.8mm clamp
• 15mm rise
• 750mm width

Grips

• ESI Chunky

Stem

• Size S: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 60mm
• Size M: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 70mm
• Size L: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 80mm
• Size XL: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 90mm

Headset

• FSA IS-2, 1-1/8" top, 1.5" bottom

Brakes

Brake Calipers

• SRAM Level Bronze, 4-piston hydraulic disc

Brake Rotors

• SRAM CenterLine, 6-bolt, round-edge, 160mm

Weight

• Size M: 13.11 kg / 28.91 lbs

Weight Limit

• Maximum combined weight (bike, rider, cargo): 300 lbs / 136 kg
