2024 Giant Revolt E+1 -

Name: 2024 Giant Revolt E+1 -
Brand: Giant
SKU: 5520001104
Price: 6499.95 CAD
Availability: InStock

5520001104

C$6 499.95

In stock

Quantity:

Product Details

Brand: Giant

FROM ROUGH ROADS TO GRAVEL, DIRT AND MIXED TERRAIN ADVENTURES, THIS VERSATILE DROP BAR E-BIKE GIVES YOU THE POWER TO RIDE FARTHER AND FASTER ON ANY ROUTE YOU CAN DREAM UP.

KEY PERFORMANCE FACTORS

Unlimited adventure

New SyncDrive EP6 motor powered by Shimano, lightweight ALUXX SL aluminum frame, smooth-riding tubeless tires and a comfortable D-Fuse seatpost give you the ability to ride any road, any route.

Powerful, integrated battery

EnergyPak Smart Compact 500 battery delivers long-distance pedaling support and is seamlessly integrated into the frame for a sleek overall profile.

System simplicity

With the press of the simple RideControl Go on/off button on the top tube, you are ready to go. The Smart Assist mode keeps you spinning without any worries. ANT+ capability further allows you to connect a bike computer of choice.

RANGE

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

ENERGYPAK 500 / SYNCDRIVE SPORT

Range
Extreme: 55 km
Good: 110 km
Ideal: 180 km

HYBRID CYCLING TECHNOLOGY
MOTOR Shimano EP600, 85Nm
CONTROLLER Mode support switch from Shimano GRX STI
DISPLAY Giant RideControl GO, frame-integrated LED consoleOptional wireless
ANT+ display
BATTERY Giant EnergyPak 500Wh Campact, Aluminium casing with highest safety
standard (EN50604), CO2 Neutral productionGiant EnergyPak Plus 250
range extender compatible

FRAME
SIZES S, M, ML, L, XL
COLOURS Phantom Green
FRAME ALUXX SL aluminum
FORK Advanced-grade composite,12x100 thru-axle
COMPONENTS
HANDLEBAR Giant Contact XR D-Fuse 31.8 alloy 5° back sweep
GRIPS Velo cork tape w/ gel
STEM Giant Contact 31.8 alloy
SEATPOST Giant D-Fuse SL, composite
SADDLE Giant Approach
PEDALS Aluminum Platform

DRIVETRAIN
SHIFTERS Shimano Ultegra Di2
REAR DERAILLEUR Shimano XT Di2
BRAKES Shimano BR-R8170, hydraulic disc, 160mm [F/R]
BRAKE LEVERS Shimano ST-R8170 hydraulic disc
CASSETTE Shimano CS-LG700-11, 11-50T, 11-speed
CHAIN KMC eGlide NP/BK, e-bike optimized
CRANKSET Shimano Steps E-bike SM-CRE80-R 47T alloy chainring Shimano Steps Ebike FC-EM600 crankarm 165mm [S], 170mm [M-XL]

WHEELS
RIMS Giant eX 2, Tubeless Ready, 700c Aluminium
HUBS Giant Performance Tracker Road, Sealed Bearing
SPOKES Sapim E-Lite [r] Race [f]
TIRES Maxxis Receptor, EXO, 700x40c (622x40), Tubeless, w/o Reflex
EXTRAS Tubeless kit (liquid, valves, levers, manual, tool)
