SMART POWER

The new SyncDrive motor has Smart Assist mode, which determines the support you need and automatically adjusts power output. A carbon belt drive (on select models) delivers clean, low-maintenance performance for added reliability in rugged off-road conditions.

FULLY INTEGRATED CONTROLS

The Ride Dash Evo with on-board navigation is cleanly integrated into the stem to help riders find their way. Cables and wires for all cockpit controls, including the brakes, dropper seatpost lever, shifters, RideControl Ergo 2 and RideDash EVO, are internally routed and tucked into the frame for a tidy aesthetic.

ADVENTURES IN COMFORT

The frame’s low-step-through design makes it easy to mount and dismount, and delivers a confident, comfortable ride. Purpose-built features including an integrated trailer mount and a rear carrier rack with a MIK HD interface makes it quick and easy to customize carrying capacity and add other accessories such as bags or a child seat with a secure click mechanism.

• Motor
  Giant SyncDrive Sport2, 75Nm, PedalPlus 6-sensor technology
• Controller
  Giant RideControl Ergo 2 remote, Smart Assist automatic mode, 5 support levels, USB-C (10W)
• Display
  Giant RideDash EVO, high-angle visibility, 3" full color LCD display, on-board navigation
• Battery
  Giant EnergyPak 625Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production
• Charger
  Giant EnergyPak 4A smart charger compact, 60% charge in 2:30h
• Connectivity
  Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
• Sizes
  S, M, L, XL
• Colours
  Pyrite Brown / Black, Snow Drift / Black
• Frame
  ALUXX SL aluminum, Integrated battery design, Headset integrated cable routing, M10 Trailer Mount, 27,5" Frame-set, KSA40 Kickstand
• Fork
  SR Suntour XCR32 ATB LO 27.5" Coil 100mm
• Shock
  n/a
• Handlebar
  Giant Contour Comfort Riser 31.8x690mm
• Grips
  Giant Comfort Ergo Microtech Plus Lock-on
• Stem
  Giant Contour, EVO integrated, high adjustable
• Seatpost
  Suspension 2-bolt micro-adjustable, 30,9x270mm
• Saddle
  Selle Royal Vivo Ergo Unisex
• Pedals
  VP VPE537, PP platform / Anti-slip
• Shifters
  Shimano Deore 10-speed
• Front Derailleur
  n/a
• Rear Derailleur
  Shimano Deore, 10-speed, Shadow+
• Brakes
  Shimano BR-MT200, hydraulic disc, 180mm
• Brake Levers
  Shimano BL-MT200
• Cassette
  Shimano Deore, CS-M4100, 11-46T, 10-speed
• Chain
  KMC e.10 Sport, e-bike optimized
• Crankset
  Alluminum 42T
• Bottom Bracket
  n/a
• Rims
  Giant eX25, Tubeless Ready, 584x25 Aluminium
• Hubs
  Shimano HB-MT200 100x9mm QR Disc [F] Shimano FH-QC400-HM [R]
• Spokes
  Stainless
• Tires
  Schwalbe Smart Sam Plus 57-584 (27.5 x 2.25"), DD, GreenGuard, ADDIX, E-50
• Extras
  KSA40 direct mount kickstand
• Lighting
  Giant Recon HL50, 50 lux [F]AXA Juno 6-12V E-bike tail light [R]
• Lock
  ABUS Xplus Battery Lock / Abus 5755L XPlus NR
• Carrier
  MIK HD rack. System bag & basket compatible
