2026 Trek Checkpoint+ SL 5 -
Product Details
Brand: TREK
UPC: 197216262091
| Category | Specification |
|---|---|
| Frame | 500 Series OCLV Carbon, TQ drive system, tapered head tube, IsoSpeed, internal routing, flat mount disc, fender mounts, UDH, 142x12mm chamfered thru axle |
| Fork | Checkpoint full carbon, tapered carbon steerer, fender mounts, triple rack mounts, flat mount disc, 12x100mm chamfered thru axle |
| Weight | ML – 13.81 kg / 30.45 lbs (with TLR sealant, no tubes) |
| Weight limit | Maximum total weight limit (bike + rider + cargo): 275 lbs / 125 kg |
| Battery | TQ 360Wh |
| Charger | TQ 4A charger |
| Computer | TQ LED display with Bluetooth & ANT+ connectivity |
| Motor | TQ-HPR60, 60 Nm, 300W max continuous, 350W peak |
| E-bike classification | Class 1 |
| Shifter | Shimano GRX RX820, 12 speed |
| Rear derailleur | Shimano GRX RX822, 51T max cog |
| Crank | XS/S: Praxis Alloy, 165mm • M/ML: Praxis Alloy, 170mm • L/XL: Praxis Alloy, 172.5mm |
| Cassette | Shimano XT M8100, 10–51, 12 speed |
| Chain | Shimano XT M8100, 12 speed |
| Max chainring size | 1x: 44T |
| Front wheel | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle |
| Rear wheel | Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, Shimano Micro Spline freehub, 142x12mm thru axle |
| Skewers | Front: Bontrager Switch chamfered thru axle • Rear: Bontrager Switch chamfered thru axle, removable lever |
| Tires | Bontrager Girona Pro, Tubeless Ready, GR puncture protection, Aramid bead, 60 tpi, 700x42mm |
| Tire sealant | Bontrager TLR, 180 ml / 6 oz |
| Rim strip | Bontrager TLR |
| Max tire size | 50mm without fenders • 42mm with fenders (as measured; see manual for details) |
| Saddle | Verse Short Comp, steel rails, 145mm width |
| Seatpost | Bontrager carbon, 27.2mm, 8mm offset, 330mm length |
| Handlebar | XS/S: 40cm • M/ML: 42cm • L: 44cm • XL: 46cm (Bontrager Elite Gravel, alloy) |
| Handlebar tape | Bontrager Supertack Perf tape |
| Stem | XS: 70mm • S/M: 80mm • ML/L: 90mm • XL: 100mm, Bontrager Elite, 31.8mm, Blendr compatible, 7° |
| Brake rotor | Shimano CL800, Centerlock, 160mm |
| Brake lever | Shimano GRX RX820, 12 speed |
| Max rotor size | 180mm front & rear |
