Specifications

Frame & Fork

Frame

• 300 Series Alpha Aluminum
• TQ drive system
• Hidden fender mounts
• Rack mounts
• Integrated frame bag mounts
• Internal cable routing
• Flat mount disc
• Integrated chainkeeper
• UDH
• 142x12mm chamfered thru axle

Fork

• Domane+ carbon
• Tapered carbon steerer
• Fender mounts
• Flat mount disc
• 12x100mm thru axle

Weight

• Size ML: 14.39 kg / 31.73 lbs (with TLR sealant, no tubes)

Weight Limit

• Maximum total weight (bike + rider + cargo): 275 lbs / 125 kg

Battery & Electronics

• Battery: TQ 360Wh
• Charger: TQ 4A charger
• Controller: TQ color LED display with Bluetooth & ANT+ connectivity
• Computer: TQ LED display with Bluetooth & ANT+ connectivity
• Motor: TQ-HPR60, 60 Nm, 300W maximum continuous, 350W peak
• E-bike Classification: Class 1

Drivetrain

Shifter

• SRAM Apex, 12 speed

Rear Derailleur

• SRAM Apex XPLR, 44T max cog

Crank

• XS, S: Praxis Alloy, 165mm
• M, ML: Praxis Alloy, 170mm
• L, XL: Praxis Alloy, 172.5mm

Cassette

• SRAM XPLR PG-1231, 11-44, 12 speed

Chain

• SRAM Apex, 12 speed

Max Chainring Size

• 1x: 46T

Bottom Bracket

• SRAM DUB Wide, T47 threaded, internal bearing

Wheels & Tires

Front Hub

• Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle

Rear Hub

• Bontrager Switch chamfered thru axle, removable lever

Rim

• Bontrager Paradigm 23, Tubeless Ready, 24H, 23mm width, Presta valve

Spokes

• 14g stainless steel, black

Tire

• Bontrager Kwaremont Pro GR, Tubeless Ready, folding bead, dual compound, 120 tpi, 700x32mm

Tire Sealant

• Bontrager TLR, 180 ml / 6 oz

Max Tire Size

• 40mm without fenders, 35mm with fenders

Contact Points

Saddle

• Verse Short Comp, steel rails, 145mm width

Seatpost

• Bontrager alloy, 27.2mm, 12mm offset, 330mm length

Handlebar

• XS: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control / 40cm drop width
• S: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control / 42cm drop width
• M, ML: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control / 44cm drop width
• L, XL: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control / 46cm drop width

Handlebar Tape

• Trek EcoTack

Stem

• XS: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 70mm
• S: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 80mm
• M: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 90mm
• ML, L: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 100mm
• XL: Bontrager Elite, 31.8mm, Blendr-compatible, 7°, 110mm

Brakes

Brake

• SRAM Apex D1 hydraulic disc, flat mount

Brake Rotor

• SRAM Paceline, rounded, centerlock, 160mm

Brake Lever

• SRAM Apex, 12 speed

Rotor Size

• Max brake rotor size: 160mm front & rear
