Frame

Sizes XXS, XS

• Alpha Silver Aluminum
• Curved top tube
• Internal derailleur & dropper post routing
• Rack & kickstand mounts
• 135x5mm ThruSkew

Sizes S, M, ML, L, XL

• Alpha Silver Aluminum
• Internal derailleur & dropper post routing
• Rack & kickstand mounts
• 135x5mm ThruSkew

Fork

Size XXS

• SR Suntour XCM 30
• Coil spring, preload, hydraulic lockout
• 42mm offset (26")
• 100mm QR
• 100mm travel

Size XS

• SR Suntour XCE 28
• Coil spring, preload
• 42mm offset (27.5")
• 100mm QR
• 80mm travel

Size S

• SR Suntour XCE 28
• Coil spring, preload
• 42mm offset (27.5")
• 100mm QR
• 100mm travel

Sizes M, ML, L, XL

• SR Suntour XCE 28
• Coil spring, preload
• 46mm offset (29")
• 100mm QR
• 100mm travel

Wheels

Front Hub

• Formula DC-20, alloy, 6-bolt, 100x5mm

Rear Hub

• Formula DC-22, alloy, 6-bolt
• Shimano 8/9/10 freehub
• 135x5mm

Rear Skewer

• 173x5mm QR

Rims

• Bontrager Connection
• Double-wall, 32-hole, 20mm internal width
• Schrader valve

Tires

Size XXS

• Bontrager Montrose Comp, wire bead, 30 tpi, 26x2.35"

Sizes XS, S

• Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.4"

Sizes M, ML, L, XL

• Bontrager Montrose Comp, wire bead, 30 tpi, 29x2.4"

Drivetrain

Shifter

• Shimano M315, 8-speed

Rear Derailleur

• Shimano ESSA U2000

Crankset
Sizes XXS, XS

• ProWheel alloy, 30T narrow-wide steel ring, 160mm crank length

Sizes S, M, ML

• ProWheel alloy, 30T narrow-wide steel ring, 170mm crank length

Sizes L, XL

• ProWheel alloy, 30T narrow-wide steel ring, 175mm crank length

Cassette

• Shimano HG300, 11–45, 8-speed

Chain

• KMC Z8.3, 8-speed

Pedals

• Nylon platform

Components

Saddle

• Bontrager Verse Short, stainless steel rails

Seatpost

Size XXS

• Bontrager alloy, 31.6mm, 12mm offset, 300mm length

Sizes XS, S, M

• Bontrager alloy, 31.6mm, 12mm offset, 330mm length

Sizes ML, L, XL

• Bontrager alloy, 31.6mm, 12mm offset, 400mm length

Handlebar

Sizes XXS, XS

• Bontrager alloy, 31.8mm, 5mm rise, 690mm width

Size S

• Bontrager alloy, 31.8mm, 15mm rise, 720mm width

Sizes M, ML, L, XL

• Bontrager alloy, 31.8mm, 15mm rise, 750mm width

Grips

• Trek Line Comp, nylon lock-on

Stem

Sizes XXS, XS, S

• Bontrager Comp, 31.8mm, 7° rise, 35mm length

Sizes M, ML, L

• Bontrager Comp, 31.8mm, Blendr-compatible, 7°, 50mm length

Size XL

• Bontrager Comp, 31.8mm, Blendr-compatible, 7°, 60mm length

Headset

• Semi-integrated, 1-1/8"

Brakes

Sizes XXS, XS, S

• Tektro HD-M276 hydraulic disc
• Power BH-M286TF hydraulic disc, 160mm rotor

Sizes M, ML, L, XL

• Tektro HD-M275 hydraulic disc
• Power BH-M286TF hydraulic disc, 180mm rotor

Brake Rotors

Sizes XXS, XS, S, M, ML, L, XL

• Tektro, 6-bolt, 160mm

Sizes M, ML, L, XL

• Tektro, 6-bolt, 180mm

Weight

• Size M: 14.90 kg / 32.85 lbs

Weight Limit

Maximum total system weight (bike + rider + cargo): 300 lb / 136 kg
