The HELM MKII newly designed damper features a new compression and mid-valve circuit for increased support and control while a new SKF oil seal head and 2.5 weight damper oil reduce friction and provide a more supple ride-feel.
The Helm MKII redesigned air spring has a new air piston designed to reduce friction, an increased air volume for better traction and suppleness, and a threadless seal head for easier travel change. In addition to the updated damper and air spring, the HELM MKII features a variety of external usability improvements including easier to turn knobs and a D-LOC bolt-on axle.
Specs
WEIGHT |
2080 grams |
DAMPING |
High Speed Compression, Low Speed Compression, Low Speed Rebound |
ADJUSTMENTS |
|
SPRING |
Double-Air spring system. High volume positive and negative air springs |
STANCHION DIAMETER |
35mm |
MIN. BRAKE ROTOR SIZE |
180mm. *If you are using a Hope Tech brake on a Helm fork, you will need to use a 200mm rotor with appropriate adapter. |
TRAVEL |
Optimized for 130-160mm of travel |
TRAVEL ADJUSTMENTS |
Internal, 10mm Increments (160mm down to 130mm) 2 Travel spacers included |
AXLE / SPACING / OFFSET |
"D-Loc" 15mm Bolt-on thru axle / 15mm x 110 BOOST spacing / 51mm and 44mm |
MAX TIRE SIZE |
64mm wide by 749mm tall (29) / 75mm wide by 739mm tall (27.5+) |
COLOR |
Gloss Black |
Features
FULLY REVISED DAMPER TUNE
- New compression and midvalve circuit for increased support and control
- New SKF low friction oil seal head cartridge
- High performance damper oil from Motorex
REDESIGNED AIR SPRING
- Increased air volume for better traction and suppleness
- New air piston for reduced friction
- New threadless air seal head for easier travel change
