Powerful assistance thanks to a Bosch Performance Line motor with 65 Nm of torque (20 mph) and 500 Wh integrated battery

Frame & Fork

• Cockpit cable integration: Yes
• Fork description: Aluminum, integrated suspension in the headset, lightweight design
• Suspension type: Integrated mono-suspension
• Frame material: Aluminum

Wheels & Tires

• Tire ETRTO size: 47-622
• Rear wheel size: 28"
• Rear hub: Continuously variable transmission
• Front rim: Double-walled aluminum for enhanced pedaling performance
• Rear rim: Double-walled aluminum for enhanced pedaling performance
• Front spokes: Reinforced stainless steel
• Front tire width: 47 mm

Transmission & Brakes

• Brake type: SE (hydraulic disc brake)
• Crankset brand: Miranda
• Crankset model: Delta
• Drivetrain: Belt drive
• Front chainring: 55 teeth
• Gear type: Hub
• Gear description: Stepless gear system
• Front brake disc diameter: 180 mm
• Rear brake disc diameter: 160 mm
• Rear sprocket: 24 teeth

Additional Equipment

• MIK carrier compatible: No
• Coat protector: No
• Rear carrier: Aluminum
• Kickstand: Drop-down rear stand

Electrical System

• Display model: Bosch Purion
• Display type: LCD
• Display description:
  Sleek and functional design — the Bosch Purion is the minimalist onboard computer ideal for both urban and countryside use. It provides all essential information at the press of a button, while your hands stay safely on the handlebars. Five different assistance modes ensure optimal support in every situation.
• Max motor torque: 65 Nm

Lighting

• Front light output: 50 lux
• Front light power source: Battery
• Rear light power source: Battery
• Rear light: LED with on/off control via the display
• Rear light model: Herrmans H-Cargo
